EX-2001 NC RACER ZSME300000091

EXCELL PRECISION CO., LTD.

CONTROL

1 2

INPUT

OUTPUT

1 2

IN / OUTPUT

7-7 OP-08 CONTROL I /O (2I /4O) INTERFACE

2 External input and relay output

Output Pin Function

1 : Zero Band

2 : HI

3 : OK

4 : LO

Input / output connectors on the rear panel

OUTPUT 1~ 4

12V

30 VDC /250 VAC1A

The output circuit of Relay

+12V

INPUT 1~2

The input circuit
