EX-2001 NC RACER ZSME300000091
7
EXCELL PRECISION CO., LTD.
CHARTER 2 SPECIFICATIONS
ANALOGUE
Load cell excitation : DC 5 V ± 5%120 mA (up to 8 × 350 load cells)
Maximum signal voltage : 20 mV
Input sensitivity : 0.3 μV / D (minimum)
Conversion rate : Approximately 120 times/s (maximum)
Internal Resolution : 19 bits
DIGITAL
Main display : 7 digits, bright red LED, 20 mm, 7-segment
Status display : 6 character display, bright red LED
Display update rate : 50 times/s
Display capacity : -199 999 to 999 999
Min division : 125102050
Decimal point : 00.00.000.0000.0 000
Memory : Calibration parameters and function settings saved in
EEPROM
