5-5 ERROR MESSAGES
(1) The load cell and A/D are abnormal.
(2) The most capacity setting value is over the high limited value.
(3) When zero calibration, load cell inputs too much. If the load cell is
not shattered, please connect a precision resistance (50 kΩ ~ 500
kΩ)
(4) Calibration resolution is less 0.3μV / d.
(5) The actual weight value is less than zero value.
(6)
The load cell output voltage is over measurable range 20 mV.
(7)
. Incorrect password.
SIG+ SIG-
EXC+
EXC-
附加
Affixation
