Excell NC RACER EX-2001 User Manual

EX-2001 NC RACER ZSME300000091
30
EXCELL PRECISION CO., LTD.
2 RS-232 Pin position
2 Refer to Chapter 9 Functions Table to set FUNC 60 ~ FUNC 69
2 The function is only to transmit but not to receive.
2
Print Format
Format 1 ( FUNC. 90=0 )
FUNC. 95 ≠ 0 ⇒ Print “SN” value FUNC. 95 = 0 ⇒ No “SN” value
DATE : 2001/08/30 DATE : 2001/08/30
TIME : 12:13:36 TIME : 12:13:36
SN. : 1 GROSS : 11.5 kg
GROSS : 11.5 kg TARE : 1.5 kg
TARE : 1.5 kg NET : 10.0 kg
NET : 10.0 kg
Format 2
( FUNC. 90=1 )
Material : 0
DATE : 2001/08/30
SN. TIME NET (kg)
1 12:14:39 11.5
2 12:14:45 6.5
SUB TOTAL
DATE : 2001/08/30
COUNT : 2
NET : 18.0
kg
3 12:14:57 8.0
SUB TOTAL
DATE : 2001/08/30
COUNT : 1
NET : 8.0 kg
GRAND TOTAL
DATE : 2001/08/30
COUNT : 3
NET : 26.0 kg
Pin number Function Pin number Function
1 TXD 3 C. LOOP1
2 SG 4 C. LOOP2
