Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2 Mobile
Fiber Inspection Probe 7
LED Indicators
Status LED Meaning
Flashing blue Processing data
Flashing red
There is a problem with the probe.
Follow the instructions on screen.
The auto focus is in timeout
There is an analysis error
Blue The probe is ready and operational
Red When the probe is connected,
indicates that the status of the
displayed measurement is Fail.
Note: Indicates the status of
the file selected in the
Measurements window.
Green When the probe is connected,
indicates that the status of the
displayed measurement is Pass.
Note: Indicates the status of
the file selected in the
Measurements window.
