Inspecting Fiber Ends
Fiber Inspection Probe 65
Inspecting Multiple Fiber Ends (MF-Ready Probes Only)
9. If the fiber end is dirty, remove it from the probe, clean it and
reinspect it.
10. Once you are satisfied with the inspection, when in high magnification
level, tap .
OR
Press the Fiber Inspection Probe handset button.
11. Go to the next connector or close the application.
Inspecting Multiple Fiber Ends (MF-Ready
Probes Only)
When you connect an MF-Ready probe to your smart device, you can view
and inspect multiple fiber ends right away. This direct viewing mode is
known as the Live Video mode.
Note: The multiple fiber ends inspection is only possible with MF-Ready probes. If
you want to inspect single fibers and transceivers with an MF-Ready probe,
see Inspecting Fiber Ends (Single Fiber and Transceiver - Fiber
Receptacles) on page 59 for details.
The multiple fiber ends inspection requires three captures. As soon as the
third capture is performed, the analysis process starts.
Note: When the internal temperature of the FIP-435B is too low, the probe
performs a warmup that can last up to a minute.
Note:
A digital watermark is added to the images generated by the application.
