Inspecting Fiber Ends
Fiber Inspection Probe 69
Inspecting Multiple Fiber Ends (MF-Ready Probes Only)
7. To indicate if you have inserted the removable nozzle key up or key
down, proceed as follows:
7a. Tap at the end of the Connector Key Orientation row.
7b. Select Key Up or Key Down.
7c. Tap Done to return to the Test Configuration window.
8. To select the fiber configuration on the connector inserted into the
removable nozzle, proceed as follows:
8a. Tap at the end of the Fiber Configuration row.
