Inspecting Fiber Ends
74 FIP-400B
Inspecting Multiple Fiber Ends (MF-Ready Probes Only)
14. To perform the third and last capture, proceed as follows:
14a.Using the trigger, slide the movable part of the inspection tip until
it stops to hide the retaining nut.
14b.Once you are satisfied with the inspection, tap .
OR
Press the Fiber Inspection Probe handset button.
When the last capture is performed, the analysis starts immediately.
Inspection tip (movable part)
