Specications
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engagesparkingbrake.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
•DeckLiftAssistPedal:Footpedalthatassistsin
raisingthedeck.
Seat
•Type:Deluxesuspensionseathighback,low
prolefoam-in-placecushion(dampened,
adjustablespringsuspension)andarmrests,
adjustablebackangle.
•Mounting:Hingedtotiltupforaccessto
hydraulicpumps,batteryandothercomponents.
Heldintiltedpositionwithscissor—typelinks.
Adjustableforeandaftseattrack.
•Armrests:Moldedadjustableip-uparmrests.
•SeatSafetySwitch:Integratedseatswitch.
Timedelayseatswitcheliminatesroughground
cut-outs.
HydrostaticGroundDriveSystem
•HydrostaticPumps:TwoHydroGearPW
variabledisplacementpistonpumps.
•WheelMotors:TwoParker/Rosswith11/4inch
taperedshafts.
•HydraulicOilType:ExmarkPremiumHydrooil.
•HydraulicOilCapacity:5.5qt.(5.2L)
•HydraulicFilter:Replaceablecartridgetype.
P/N103-2146:25microns,Nobypass
•Speeds:
–0-12.0mph(19.3km/hr)forward.
–0-8.0mph(12.9km/hr)reverse.
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
Tires&Wheels
DriveFrontCaster
Pneumatic
(Air-Filled)
Semi-Pneumatic
Quantity
22
DriveFrontCaster
TreadSize
“Multi-TracC/S”
Smooth
Size26x12.00-1213x6.50-6
PlyRating
4
Pressure
10psi(69kPa)
CuttingDeck
•CuttingWidth:
–60inch(152.4cm)
–72inch(182.9cm)
•Discharge:Side
•BladeSize:(3ea.)
–60inchDeck:20.75inches(52.7cm)
–72inchDeck:24.75inches(62.9cm)
•BladeSpindles:Solidsteelspindleswith1.18inch
(30mm)I.D.bearings.
•DeckDrive:
–Electricclutchmountedonhorizontalengine
shaft.“B”Sectionbelt(withself-tensioning
idler)fromelectricclutchtotransfershaft
mountedondeck.
–Bladesaredrivenbyone“B”Sectionbelt
(w/self-tensioningidler)fromtransfershaft
ondecktobladespindles.
•Deck:
Fulloatingdeckisattachedtoout-frontsupport
frame.Sixanti-scalprollersprovidemaximum
turfprotection.Deckdesignallowsforbagging,
mulchingorsidedischarge.
•DeckDepth:
–60inchDeck:6.0inches(15.2cm)
–72inchDeck:6.0inches(15.2cm)
•CuttingHeightAdjustment:
Anextra-longcushionedleverisusedtoadjust
thecuttingheightfrom1inch(2.5cm)to5inches
(12.7cm)in1/4inch(6.4mm)increments.The
cuttingheightadjustmenthandlehasatransport
positionandalladjustmentscanbemadewhile
theoperatorremainsseated.Unitsalsohavea
footoperateddeckliftassistlevertoaidinraising
thedeck.
•MulchingKit:Optional.
