Maintenance
(bushingsarelocatedtotheinsideoftheange
bearings).
LubricateMotionControl
BronzeBushings
ServiceInterval:Every160hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Unhookseatlatchandtiltseatup.
3.Lubricatebronzebushingsonangebearings
securingthemotioncontrolarmshaftswitha
lightoiloraspraytypelubricant.
DrainFuelFilter/Water
Separator
ServiceInterval:Every40hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Placeadrainpanunderthefuellterandloosen
thedrainplugapproximately1turn.
3.Watershoulddrain.
4.Whenfuelbeginstoowfromthelter,tighten
thedrainplug.
Important:Waterorothercontaminantsinfuel
canseverelydamagefuelpumpand/ortheother
enginecomponents.
ChangeFuelFilter/Water
Separator
ServiceInterval:Every400hours/Yearly
(whichevercomesrst)
(moreoftenindirtyor
dustyconditions).
DANGER
Useofimpropercomponentscanresultinsystem
failure,fuelleakageandpossibleexplosion.
•EnsurethatanAuthorizedServiceDealer
replacethefuellterandanycomponentsfor
thefuelsystem.
•Useonlyapprovedfuellines,hoseclamps
andfuelltersforhighpressuresystems.
ChangeInlineFuelFilter
ServiceInterval:Asrequired
Aninlinefuellterisinstalledbetweenthefueltank
andthefuelpump.Replacewhennecessary.
ReplacementFilters
ExmarkP/N112-7836
ChangeHydraulicSystem
Filter
ServiceInterval:Aftertherst250hours
Every500hours/Yearly
(whichevercomes
rst)thereafter
(Every250hours/Yearlyif
usingMobil115W50)
Note:UseonlyExmarkP/N103-2146.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Raiseseat.
3.Carefullycleanareaaroundlter.Itisimportant
thatnodirtorcontaminationenterhydraulic
system.
4.Unscrewltertoremoveandallowoiltodrain
fromreservoir.
Important:Beforereinstallingnewlter,ll
itwithExmarkPremiumHydrooilandapply
athincoatofoilonthesurfaceoftherubber
seal.
Turnlterclockwiseuntilrubbersealcontactsthe
lteradapter,thentightenthelteranadditional
2/3to3/4turn.
5.FillreservoirasstatedinCheckHydraulicOil
Levelsection.
ExmarkPremiumHydroOilisrecommended.
Refertothechartforanacceptablealternative:
HydroOil
ChangeInterval
ExmarkPremiumHydro
Oil(Preferred)
500Hours
Mobil115W50
250Hours
