Exmark LAZER Z DS-SERIES User Manual

Maintenance
Figure26
1.Feelergauge
•Ifthegapislessthan0.010inch,then
reinstalltheshimandreferencethe
Troubleshootingsection.
•Ifthegapissufcient,proceedtothe
safetycheckinstep
F.
F.Performthefollowingsafetycheck:
a.Sitontheseatandstarttheengine.
b.MakesurethebladesDoNotengagewith
thePTOswitch“off”andtheclutch
disengaged.
Iftheclutchdoesnotdisengage,
reinstalltheshimandreferencethe
Troubleshootingsection.
c.EngageanddisengagethePTOswitch
tenconsecutivetimestoensuretheclutch
isfunctioningproperly.Iftheclutch
doesnotengageproperly,referencethe
Troubleshootingsection.
ReverseIndicator
Adjustment
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Unhookseatlatchandtiltseatforward.
3.Beginwitheithertheleftorrightmotioncontrol
lever.Movelevertotheneutralpositionandpull
leverbackuntiltheclevispin(onarmbelowpivot
shaft)contactstheendoftheslot(justbeginning
toputpressureonspring).(Figure27).
4.Checkwhereleverisrelativetonotchinconsole
(shouldbecenteredallowinglevertopivot
outwardtotheneutrallockposition).
5.Ifadjustmentisneeded,loosenthenutagainstthe
yokeandwhileapplyingslightrearwardpressure
onthemotioncontrollever,turntheheadofthe
adjustmentboltintheappropriatedirectionuntil
leveriscentered(keepingrearwardpressureon
theleverwillkeepthepinattheendoftheslot
andallowtheadjustmentbolttomovethelever
totheappropriateposition).Tightenlocknut.
6.Repeatonoppositesideofunit.
Figure27
1.Turnbolthere4.Yoke
2.Levercenteredinnotch5.Loosenhere
3.Endofslot
6.Reverseindicator
MotionControlLinkage
Adjustment
WARNING
Enginemustberunninganddrivewheelsmust
beturningsomotioncontroladjustmentcanbe
performed.Contactwithmovingpartsorhot
surfacesmaycausepersonalinjury.
Keepngers,hands,andclothingclearof
rotatingcomponentsandhotsurfaces.
45
