Operation
andmovingthethrottlelevertotherearwilldecrease
enginespeed.Movingthethrottleforwardintothe
detentisfullthrottle.
BrakeLever
Locatedonleftsideofunit,justtothefrontofthe
console.
Thebrakeleverengagesaparkingbrakeonthedrive
wheels.
Pulltheleverupandrearwardtoengagethebrake.
Pushtheleverforwardanddowntodisengagethe
brake.
Theunitmustbetieddownandbrakeengagedwhen
transporting.
IgnitionSwitch
Locatedonrightfueltank.
Theignitionswitchisusedtostartandstopthe
engine.Theswitchhasthreepositions“OFF”,“ON”
and“START”.Insertkeyintoswitchandrotate
clockwisetothe“ON”position.Rotateclockwiseto
thenextpositiontoengagethestarter(keymustbe
heldagainstspringpressureinthisposition).
Note:Brakemustbeengaged,motioncontrollevers
out(neutrallockposition)andPTOswitch“OFF”to
startengine.(Itisnotnecessaryfortheoperatorto
beintheseattostarttheengine.)
HourMeter
Locatedontherightfueltank.
Thehourmeterisconnectedtoapressureswitch
installedintheengineblockanditrecordsthe
numberofhoursthattheenginehasrun.Ifthe
ignitionswitchisleftonwithoutenginerunning,
hourmeterwillnotrun.
Note:Thisswitchisnotalowoilsensorandwillnot
alerttheoperatoriftheengineoilislow.
FuelShut-OffValve
Locateddirectlybelowtherightsideofconsole,next
tothecubby.
Thefuelshut-offvalveisusedtoshutoffthefuel
whenthemachinewillnotbeusedforafewdays,
duringtransporttoandfromthejobsite,andwhen
parkedinsideabuilding.
Thevalvehasthreepositions,eachpositionmade
in1/4turnincrements.
FuelFlowValveHandlePosition
“Off”Right
RightTank
Down
LeftTankLeft
FuelGauge
Locatedontheleftfueltank.
Thefuelgaugemonitorstheamountoffuelintheleft
tankonly.Usethefuelfromtherightfueltankrst.
Whentherightfueltankisempty,switchtotheleft
fueltank.Fuelgaugewillmonitortheremainingfuel.
DriveWheelReleaseValves
Locatedonthetoprightfrontcornerofhydrostatic
pumps.
Drivewheelreleasevalvesareusedtoreleasethe
hydrostaticdrivesystemtoallowthemachinetobe
pushedwithouttheenginerunning.Unhookseat
latchandtiltseatuptogainaccesstopumps.
Witha5/8inchwrench,turnbothvalvesoneturn
counterclockwisetoreleasedrivesystem.Turn
clockwisetoresetsystem.DoNotovertighten.Do
Nottowmachine.
TrackingAdjustmentKnob
LocatedundertheseatontheLHpumpcontrollink.
Rotatingthisknoballowsnetuningadjustmentsso
thatthemachinetracksstraightwiththedrivelevers
inthefullforwardposition.
Stopmachineandwaitforallmovingpartstostop.
Engageparkbrake.Unhookseatlatchandtiltseat
forwardtogainaccesstothetrackingknob.Rotate
theknobclockwise(asviewedfromtherearofthe
machine)tocausethemachinetotrackmoretothe
rightandcounterclockwisetocausethemachine
totrackmoretotheleft.Adjustinquarter-turn
incrementsuntilthemachinetracksstraight.Check
thatthemachinedoesnotcreepwheninneutralwith
theparkbrakedisengaged.
Important:DoNotrotatetheknobtoofar,as
thismaycausethemachinetocreepinneutral.
RefertotheMotionControlLinkageAdjustment
sectioninMaintenance.
