Operation
ProductOverview
Figure4
1.Motioncontrollevers
5.EngineControls(right
console)
2.Parkingbrake
6.Seatbelt
3.Heightofcutadjustment
7.RolloverProtection
System(ROPS)
4.Fuelcap(bothsides)
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Controls
MotionControlLevers
Themotioncontrolleverslocatedoneachsideof
theconsolecontroltheforwardandreversemotion
ofthemachine.
Movingtheleversforwardorbackwardturns
thewheelonthesamesideforwardorreverse
respectively.Wheelspeedisproportionaltothe
amounttheleverismoved.
Movingtheleversoutwardfromthecenterposition
intotheT-slotlocksthemintheneutralposition
(
Figure5).
Figure5
1.Neutrallockposition
(handlesout)
5.Neutral(operate)
2.Neutraloperateposition
(handlesin)
6.Reverse
3.FrontofUnit
7.Neutrallock
4.Forward
ThrottleControl
Locatedonrightfueltank.
Thethrottleisusedtocontrolenginespeed.Moving
thethrottleleverforwardwillincreaseenginespeed
20
