Operation
Toturnright,releasepressureontheRHmotion
controlleverandtherearofthemachinewill
movetowardstherearandtotheright.
Toturnleft,releasepressureontheLHmotion
controlleverandtherearofthemachinewill
movetowardstherearandtotheleft.
3.Tostop,positionbothmotioncontrolleversin
theneutraloperateposition.
AdjustingtheCuttingHeight
Thecuttingheightofthemowerdeckisadjusted
from1to5inches(2.54cmto12.7cm)in1/4inch
(6.4mm)increments.
1.Stopthemachineandmovethemotioncontrol
leversoutwardtotheneutrallockedposition.
2.DisengagethePTO.
3.Raisethedeckheightlevertothetransport
position(alsothe5inch(12.7cm)cuttingheight
position)(
Figure10).
Thedeckcanberaisedbypullingthedecklever
upand/orbypushingdownonthefootoperated
deckliftassistleverlocatedatthefrontright
corneroftheoorpan.
Note:Whenchangingthecuttingheight
positions,alwayscometoacompletestop
anddisengagethePTO.
Figure10
1.Leverintransportand5inch(12.7cm)cuttingheight
position
4.Inserttheheightadjustmentpinintothehole
correspondingtothedesiredcuttingheightand
installthehairpincotterpin.
Seethedecalonthesideofthedeckliftplatefor
cutheights.
5.Movethedeckheightleveroutofthetransport
position(or5inch(12.7cm)cuttingheight)and
downontotheheightadjustmentpintomowat
selectedheight.
Note:Thefootoperateddeckliftassistlever
canbeusedtomomentarilyliftthedecktoclear
objects.BesurethatPTOisdisengaged.
AdjustingtheAnti-ScalpRollers
Itisrecommendedtochangetheanti-scalproller
positionwhentheheightofcuthaschanged.
1.Stopthemachineandmovethemotioncontrol
leversoutwardtotheneutrallockedposition.
2.DisengagethePTO.
3.Engagetheparkbrake.
4.Stoptheengine,removethekeyandwaitforall
movingpartstostop.
5.Afteradjustingtheheightofcut,adjustthe
anti-scalprollersbyremovingtheboltandspring
discwasher.
6.Placetherollersinoneofthepositionsshown
(
Figure11).Rollerswillmaintain3/4inch(19
mm)clearancetothegroundtominimizegouging
androllerwearordamage.
Figure11
Forcuttingheightsabove4.0inches(102mm)usethe
bottomhole.Therollerswillstillbeeffectiveagainst
scalping.
1.Anti-scalproller
mountingbracket
2.Cuttingheight
ForMaximumDeckFlotation,placetherollers
oneholepositionlower.Rollersshouldmaintain
1/4inch(6.4mm)clearancetotheground.Do
Notadjusttherollerstosupportthedeck.
26
