Operation
g224810
Figure12
1.Decksupportpin
2.CuttingHeight
B.Checktirepressureindrivetiresandinateto
12-14psi(83-97kPa)ifnecessary.
Measurethecircumferenceofeachdrivetire.
Adjusttirepressureswithintheaboverange
totrytomaketirecircumferencesmatchas
closelyaspossible.
C.Thelengthofthereardecksupportlink
assembliesaverage6.38inches(162mm)from
thecenteroftheballjointtothecenterofthe
farthesthole;seeFigure13.
Note:Allfourpinsmustequallysupportthe
weightofthedeck.Adjustmentinthelength
ofthereardecksupportassembliesmaybe
necessary.Ifonesideislongerthan6.38
inches(162mm),thantheoppositesidemust
beshorterbythesameamount.
g303985
Figure13
LeftHandSideShown
1.3/8inch(9.5mm)3.6.38inches(162mm)
2.1/4inch(6.4mm)
4.Decksupportrod
7.Repeatsteps5and6fortheoppositeside.
8.Liftdecktounlatch(Figure14).
Note:Deckheightchangeassistleversarenot
intendedtobeusedascutheightpositions.
Duringoperation,vibrationandjerkymovements
couldliftthecuttingdeckenoughtoallow
disengagementoflevers.Thiswillresultin
suddendropofthecuttingdeck,causingpossible
damage.Leverscanbeusedtoholdthedeckup
forloadingandunloadingfromatrailer.
