6.2.3 End of lock angle reserve reached (end of lock angle reserve)
If the switch-off angle is more than 5 degrees outside of the lock
movement, the warning "End lock angle" and "System fault" are
output to the PLC simultaneously.
Do not continue to operate the turntable. Further operation can
cause damage to the drive elements.
CAUTION!
Switch-off over 5 degrees.
Further operation can cause damage to the drive
elements!
Therefore:
– Do not continue to operate the turntable.
– Eliminate the cause.
Possible causes: Measures
Brake pads are worn or the brake is defective Check the brake and replace it if necessary
Mech. damage on the turntable Check turntable for mechanical damage
Reset fault
NOTE!
Eliminate cause.
Unscrew the cover on the turntable controller and press the reset
button for at least 3s.
Press the reset button and the default values will be used for
turntable control.
