Expert SmartTurn - 7 Smartturn - Spare Parts; Dok-ID:EXPERT-0003-EN

Turntable control SmartTurn
SmartTurn – spare parts
Dok-ID:EXPERT-0003-EN-2011 67
7 SmartTurn – spare parts
Designation Part number
Sensor 502765
Sensor actuator 504480
Control unit, SmartTurn 2011 510937
Sensor cable 5 m 504775
Diagnostics cable 2 m 517719
Position sensing - standard for max. 8 positions:
 Sensor
 Transponder
 Connecting line 10 m
506815
X*
506000
Position sensing - standard for max. 15 positions:
 Sensor
 Transponder
 Connecting line 10 m
506815*
X*
506000
Position sensing - safety:
 Sensor
 Transponder
 Connecting line 10 m
505986
505987
505988
Coupling M23x1, 19-pin with connecting cable
16x0.5+3x1 mm² for plug X1, length=5 m
646303
Coupling M23x1, 19-pin with connecting cable
16x0.5+3x1 mm² for plug X1, length=10 m
664564
Coupling M23x1, 19-pin with connecting cable
16x0.5+3x1 mm² for plug X1, length=15 m
664565
Coupling M23x1, 19-pin with connecting cable
16x0.5+3x1 mm² for plug X1, length=20 m
664567
Coupling M12x1, 4-pin with connecting cable 4x0.75
mm² for plug X2, length=5 m
527697
Coupling M12x1, 4-pin with connecting cable 4x0.75
mm² for plug X2, length=10 m
527696
Coupling M12x1, 4-pin with connecting cable 4x0.75
mm² for plug X2, length=15 m
527695
