Turntable control SmartTurn
Faults
Dok-ID:EXPERT-0003-EN-2011 63
6.3.6 Changed lock angle
Lock angle setting deviates from the saved lock angle setting or
change of the lock angle on switch S1.
Possible causes Measures
Reverse mode / continuous mode
Continuous mode, reverse mode
None
Reset fault
NOTE!
Eliminate cause.
Unscrew the cover on the turntable control unit.
Press the reset button for at least 3 s.
System fault LED goes out.
Turn the turntable several times at operating speed.
Press the reset button and the default values will be used for
turntable control.
NOTE!
Comply with the supplemental instructions in the
section -> Commissioning
