Turntable control SmartTurn
Faults
Dok-ID:EXPERT-0003-EN-2011 61
6.3.4 Change mode (changed rotary mode)
The mode deviates from the saved mode or impermissible level
change on input E4 "Mode"
Change from position 9 to position 1-4 or vice versa on rotary
switch S1.
Possible causes Measures
Mode change from:
- Continuous run in reverse mode
- Special to reverse mode (change from position 9 to
1-4 on rotary switch S1)
Reverse mode:
Turn drive roller (position encoder) a min. 45
degrees outside of the 0-position in the movement
range between the positions "Front" and "Back".
Mode change from:
- Reverse mode to continuous mode
- Special to continuous mode (change from position 9
to 1-4 on rotary switch S1)
- Continuous to special mode (change from position 9
to 1-4 on rotary switch S1)
Continuous mode, special mode:
None
Reset fault
NOTE!
Eliminate cause.
Unscrew the cover on the turntable control unit.
Press the reset button for at least 3 s.
System fault LED goes out.
Turn the turntable several times at operating speed.
Press the reset button and the default values will be used for
turntable control.
NOTE!
Comply with the supplemental instructions in the
section -> Commissioning
