Expert SmartTurn - Wrong Rotary Direction (Direction Forward; Backward)

Turntable control SmartTurn
Faults
64 Dok-ID:EXPERT-0003-EN-2011
6.3.7 Wrong rotary direction (direction forward / backward)
At each start the rotary direction of the drive roller is checked
against the setting on switch S3 clockwise/counter-clockwise.
Possible causes Measures
The actual rotary direction of the drive roller does
not agree with the setting on S3 clockwise/counter-
clockwise
Reverse mode
Reverse mode:
 Turn drive roller (position encoder) a min. of 45
degrees outside of the 0-position in the
movement range between the positions "Front"
and "Back".
 Change the motor rotary field or change setting
S3 so that the desired rotary direction of the
turntable forward/backward agrees with the
setting on S3.
Continuous mode
 Change the motor rotary field or change setting
S3 so that the desired rotary direction of the
turntable forward/backward agrees with the
setting on S3.
Reset fault
NOTE!
Eliminate cause.
 Unscrew the cover on the turntable control unit.
 Press the reset button for at least 3 s.
 System fault LED goes out.
 Turn the turntable several times at operating speed.
Press the reset button and the default values will be used for
turntable control.
NOTE!
Comply with the supplemental instructions in the
section -> Commissioning
