Faults
62 Dok-ID:EXPERT-0003-EN-2011
6.3.5 Change mode (changed rotary direction)
Rotary direction deviates from the saved rotary direction or change
rotary direction right/left on switch S3.
Possible causes Measures
Reverse mode / change S3
Reverse mode:
Turn drive roller (position encoder) a min. 45
degrees outside of the 0-position in the
movement range between the positions "Front"
and "Back"
Continuous mode / change S3
Continuous mode – special mode:
None
Reset fault
NOTE!
Eliminate cause.
Unscrew the cover on the turntable control unit.
Press the reset button for at least 3 s.
System fault LED goes out.
Turn the turntable several times at operating speed.
Press the reset button and the default values will be used for
turntable control.
NOTE!
Comply with the supplemental instructions in the
section -> Commissioning
