Faults
60 Dok-ID:EXPERT-0003-EN-2011
6.3.3 Invalid sensor data (changed sensor position)
If after switching on the operating voltage, a deviation from the last
saved position is detected, this results in a fault.
Possible causes Measures
Turntable has been dismantled and no longer has
the same position
The turntable has been turned without operating
voltage applied on the turntable controller
Failure of the 24 V power supply while the turntable
is turning
Reverse mode:
Turn drive roller (position encoder) a min. of
45 degrees outside of the 0-position in the
movement range between the positions "Front"
and "Back"
Continuous mode and special mode:
None
Reset fault
NOTE!
Eliminate cause.
Unscrew the cover on the turntable control unit.
Press the reset button for at least 3 s.
System fault LED goes out.
Turn the turntable several times at operating speed.
Press the reset button and the default values will be used for
turntable control.
NOTE!
Comply with the supplemental instructions in the
section -> Commissioning
