6. Carefully slide the power supply all the way into the power supply bay.
Figure 85: Installing an ExtremeSwitching 2000 W AC Power Supply
7. Push the power supply in until the latch snaps into place.
Caution
Do not slam the power supply into the switch.
8. Connect the power cord to the power supply and to a grounded AC power outlet.
Warning
Always be sure that the source outlet is properly grounded before plugging the AC power
cord into the AC power supply.
9. If the power supply is equipped with a power cord retainer, use the retainer to secure the power cord
to the power supply.
Replace a 2000 W AC Power Supply
Replacing AC Power Supplies
120 ExtremeSwitching 5520 Series Hardware Installation Guide
