Port Partitioning
On some ExtremeSwitching switch models, you can configure QSFP28 and QSFP+ ports either as single
ports or as multiple, partitioned ports. In a partitioned port, with appropriate cabling, the original
physical port can accommodate multiple data lanes at lower bandwidths.
The following partitioning options are available:
Table 4: QSFP28 Port Partitioning
Switch model Port bandwidth Port partitions
5520 (all models)
QSFP28
100 Gb One QSFP28 port with one of the following:
• Two 50 Gb ports
• One 40 Gb port (default)
• Four 25 Gb ports
• Four 10 Gb ports
Note: These ports do not support 1x100Gb
For information about configuring partitioned ports, see the ExtremeXOS 31.1 Command Reference
Guide.
22
ExtremeSwitching 5520 Series Hardware Installation Guide
