Table 61: V400 Packaged Dimensions (continued)
V400-48t-10GE4 Height: 4.49 in (11.4 cm)
Width: 14.66 in (37.2 cm)
Length: 22.02 in (55.9 cm)
V400-48p-10GE4 Height: 4.49 in (11.4 cm)
Width: 19.86 in (50.4 cm)
Length: 22.02 in (55.9 cm)
Table 62: V400 Packaged Weight
V400-24t-10GE2 9.00 lb (4.08 kg)
V400-24p-10GE2 11.44 lb (5.19 kg)
V400-48t-10GE4 9.69 lb (4.39 kg)
V400-48p-10GE4 16.56 lb (7.50 kg)
Power Specifications
Note
When you use a redundant power supply (RPS), only redundant power – not additive power –
is supported. Thus, the PoE ports load does not increase when an RPS is added.
Table 63: V400 Power Options
V400-24t-10GE2 AC Input: 100-240 VAC, 50/60 Hz, 0.6 A max
V400-24p-10GE2 AC Input: 100-240 VAC, 50/60 Hz, 2.2 A max
DC RPS input: 54 VDC, 18.52 A max
• PoE ports load to 382 W for AC input only.
• PoE ports load to 720 W for DC input only.
• PoE ports load to 720 W for AC+DC input.
V400-48t-10GE4 AC Input: 100-240 VAC, 50/60 Hz, 1.0 A max
V400-48p-10GE4 AC Input: 100-240 VAC, 50/60 Hz, 12.0 - 6.0 A max
DC RPS input: 54 VDC, 18.52 A max
• PoE ports load to 740 W for AC input only.
• PoE ports load to 900 W for DC input only.
• PoE ports load to 1440 W for AC+DC input.
Technical Specifications Power Specifications
ExtremeSwitching 5520 Series Hardware Installation Guide 139
