2 = USB 1 port 4 = Stacking/QSFP28 ports 6 = 100Mb/1/2.5/5Gb multi-rate ports
The rear panel of the switch includes:
• 3 fan modules
• Grounding lug
• 1 Type-A USB port
• 2 power supply slots
Figure 8: 5520-12MW-36W Rear Panel
1 = Fan modules 3 = Serial console port 5 = USB 2 port
2 = Grounding lug 4 = OOB management port 6 = Locator LED
7 = Power supply slots
5520-48T Switch Features
The front panel of the 5520-48T switch includes:
• 48 10/100/1000Mb full/half duplex MACsec capable ports
Note
Half-duplex is not supported on these ports when operating at 1Gbps.
• 1 VIM slot
• 1 Type-A USB port
• 1 Micro-B USB console port
• 2 Stacking/QSFP28 ports
Figure 9: 5520-48T Front Panel
5520-48T Switch Features
ExtremeSwitching 5520 Series Overview
18 ExtremeSwitching 5520 Series Hardware Installation Guide
