5520-VIM-4YE Versatile Interface Module
The 5520-VIM-4YE versatile interface module provides four 25-GbE (SFP28) MACsec capable ports.
Note
In VOSS, you must use the vim-speed command to set the speed to 10G or 25G for 5520-
VIM-4YE. The default is 25G.
In EXOS, use the configure ports partition command with 4x25 or 4x10.
For information about the supported optical modules, refer to the most recent version of the Extreme
Optics website.
Figure 30: 5520-VIM-4YE Versatile Interface Module
Table 14: Port Numbers for Ports on the 5520-VIM-4YE Module
5520 Series 24-port models 5520 Series 48-port models VOSS (all models)
33-36 (EXOS) 57-60 on 48-port models (EXOS) VIM slot number=2
Interface names=2/1-2/4
5520-VIM-4YE Versatile Interface Module Expansion Modules
36 ExtremeSwitching 5520 Series Hardware Installation Guide
