The V300HT-8T-2X model requires that ExtremeXOS (EXOS) version 30.6 (or later) be installed on the
switch to which it is attached. For more information about configuring EXOS for use with this
equipment, see the ExtremeXOS 31.1 User Guide.
The V300HT-8T-2X model is compatibile with the following power supplies:
• Model XN-ACPWR-40W-HT - a 40W AC power supply high temperature
• Model XN-ACPWR-60W-HT-DIN - a 60W AC power supply high temperature DIN rail compatible
Important
The high temperature power supplies for the V300HT models require field wiring. Power
supplies must be installed in accordance with local electrical codes by a licensed electrician.
Note
Power supplies for this model are sold separately.
Figure 23: V300HT-8T-2X Front Panel
1 = DC inputs
2 = 10/100/1000BASE-T ports
3 = 10Gb SFP+ ports 4 = USB port
5 = Console/Management port
Figure 24: V300 Virtual Port Extender Rear Panel
Expansion Modules
V300HT-8T-2X Model
ExtremeSwitching 5520 Series Hardware Installation Guide 31
