FOX3 T 201 Transmitter • SIS Configuration and Control 24
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Timeout Ethernet data port
Set current port timeout
E
0*
X3!
TC
}
Pti0*
X3!]
View current port timeout
E
0TC
} X3!]
KEY:
X3!
= Timeout The number of seconds before timeout on IP connections (min=1, max=6500 , with each number equivalent to
10 seconds [default=30=300 seconds])
IP address
Set IP address
E X1!
CI
}
Ipi•
X1!]
View IP address
E
CI
} X1!]
KEY:
X1!
= IP address xxx.xxx.xxx.xxx
RS-232 COMM settings
Set serial port parameters
EX1^
*
X1@
,
X1#
,
X1$
,
X1%
CP
}
Cpn
X1^
• Ccp
X1@
,
X1#
,
X1$
,
X1%]
KEY:
X1@
= Baud rate 300 − 115200 baud (9600 default)
X1#
= Parity odd, even, none (default), mark, space (only the first letter required)
X1$
= Data bits 7, 8 (default)
X1%
= Stop bits 1 (default), 2
X1^
= UARTs 1 = endpoint (this is the default for the device)
Resets
Erase all files from flash memory
E
ZFFF
}
Zpf
]
Removes files created in user space.
Reset unit settings
E
ZXXX
}
Zpx
]
Resets unit to factory default.
Absolute system reset (retain IP)
E
ZY
}
Zpy
]
Same as
E
ZQQQ except excludes IP
settings.
Absolute system reset
E
ZQQQ
}
Zpq
]
Master Reset, resets IP address and
subnet mask to default. Also resets all
installed cards.
IP system reset
E
1ZQQQ
}
Zpq1
]
Resets only IP settings.
Reset audio gain and attenuation
E
ZA
}
Zpa
]
Reset audio gain & attenuation to default
levels.
Global unsolicited response
Input change
Recong
]
Any change of the input frequency, during
module install, or a power cycle.
Fiber link
Sts02*
X1*
*
X2*]
Any change in fiber link status.
Input video signal presence
SigI
X$]
Any change in input signal status.
Input HDCP
HdcpI
X^]
Any change in input HDCP status.
Output HDCP
HdcpO
X&]
Any change in output HDCP status.
Audio input status
Sts05*
X%]
Displays input audio selection status.
KEY:
X$
= Input video signal status 0 = Not detected 1 = Detected
X%
= Input audio status 0 = Not detected 1 = Detected
X^
= Input HDCP status 0 = No source detected 1 = Source with HDCP detected
2 = Source with no HDCP present
X&
= Output HDCP status 0 = No active sink detected 1 = Sink detected, output encrypted
2 = Sink detected, output not encrypted
X1*
= Active fiber link 1 = SFP A 2 = SFP B
X2*
= Fiber Link detection (SPF A/B IN LED) 0 = Not detected 1 = Detected
NOTE: SFP A and SFP B OUT LED is always active
