FOX3 T 201 Transmitter • SIS Configuration and Control 25
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
HDCP authorized device
Set HDCP authorized device on
E
E1HDCP
}
HdcpE1
]
Set HDCP authorized device off
E
E0HDCP
}
HdcpE0
]
View HDCP authorized device
E
EHDCP
}
Verbose mode 2/3:
X1(]
HdcpE
X1(]
Default: HDCP authorized on.
KEY:
X1(
= Input HDCP Authorization 0 = HDCP authorized off 1 = HDCP authorized on (default)
Input audio selection
Select audio input
EIX*AFMT} AfmtIX*]
Default. Digital has priority.
View selected audio input
EIAFMT} X*]
KEY:
X*
= Input audio selection 0 = Auto (default) 1 = Digital 2 = Analog
Input signal detection information
View detected input signal
information
35I/i
Res
X2)
•AudI
X2!
•VcsI
X2@
•Pixcl
X2#]
Verbose mode 2/3:
Inf35*
Res
X2)
•AudI
X2!
•VcsI
X2@
•Pixcl
X2#
]
KEY:
X1(
= Input HDCP Authorization 0 = HDCP authorized off 1 = HDCP authorized on (default)
X2)
= Resolution and refresh rate nnnn
Horizontal
xnnnn
Vertical
@
xxHz (0000x0000@000Hz = no input detected)
X2!
= Detected input audio format 0 = Not detected 1 = Digital 2 = Analog
X2@
= Detected video input color space 0 = Not detected 1 = YUV 2 = RGB
X2#
= Pixel clock (in MHz) 4‑digit response with 0 padding (example: 294 = 0297MHZ) (0000 = Not detected)
Force 4K60 compressed mode
Force 4K 60 compressed mode
EC1FOXM}
FoxmC1
]
Sends 4K60 signal compressed on 1 fiber
Disable 4K 60 comressed mode
EC0FOXM}
FoxmC0
]
Sends 4K60 signal uncompressed on 2
fibers
View 4K 60 compressed mode
status
ECFOXM}
Verbose mode 2/3
X2$]
FoxmC
X2$]
NOTE: This command only applies to devices with the 4K60 Uncompressed Video LinkLicense or transmitter units with part numbers ending with
‑13 or ‑14. If the command is issued to the wrong unit, return E14.
KEY:
X2$
= Force 4K60 compressed mode 0 = Disable (default; after a reset, setting defaults back to 0) 1 = Force 4K60 on 1 fiber
