IN1804 Seamless Scaling Switchers • Operation 33
Output Resolutions and Rates
Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz
640x480 X
800x600 X
1024x768 X
1280x768 X
1280x800 X
1280x1024 X
1360x768 X
1366x768 X
1440x900 X
1400x1050 X
1600x900 X
1680x1050 X
1600x1200 X
1920x1200 X
480p X X
576p X
720p X X X X X X
1080i X X X
1080p X X X X X X X X*
2048x1080 (2K) X X X X X X X X
2048x1200 X
2048x1536 X
2560x1080 X
2560x1440 X
2560x1600 X
3840x2160 X X X X X
X** X** X**
4096x2160 X X X X X
X*** X*** X***
*Default output resolution
**Rate supported only with 4:2:0 color sampling for IN1804 DI, DO, and DI/DO models when in
DTP, XTP, or HDBT mode. 4:4:4 sampling is available via HDMI outputs or DTP2 endpoints only.
***Rate available only with 4:2:0 color sampling when using any twisted pair output. 4:4:4
sampling is available via HDMI outputs only.
• HDMI 1A or TP 1A Format — After selecting HDMI 1A Format (IN1804 standard and
IN1804 DI) or TP 1A Format (IN1804 DO and IN1804 DI/DO) from the list of Output
submenu items, press the

or  buttons to select the output format. The format
choices include:
• Auto (based on the EDID of the sink) (default)
• DVI RGB 444
• HDMI RGB 444 Full
• HDMI RGB 444 Ltd
• HDMI YUV 444 Ltd
• HDMI YUV 422 Ltd
• HDMI YUV 420 Ltd*
*Available only for 3840x2160 and 4096x2160 resolutions.
