IN1804 Seamless Scaling Switchers • SIS Configuration and Control 58
X6@
= Power Save mode
0 = Full power mode (default)
1 = Lowest power state — TP remote power and TP
links are disabled. Input LEDS 1 through 4 cycle at a
500 ms interval.
2 = Lower power mode — TP links remain active,
including remote power, and Ethernet to RS-232
insertion. Input LEDS 1 through 4 cycle at a 500 ms
interval.
9 = Low power state due to over-heating
(query-response only)
X6#
= Screen saver status
0 = Active input detected, timer not running
1 = No active input, timer running, output sync still active
2 = No active input, timer expired, output sync disabled
X6$
= Port timeout Set time in seconds before the port connection times out.
1 (10 seconds) through 65000 (650,000 seconds)
Default = 30 (300 seconds)
X6%
= Start point for UART ports Start point for UART ports:
TP IN4 =
X6%
+ 1 (IN1804 DI and DI/DO only)
TP OUT 1A =
X6%
+ 3 (IN1804 DO and DI/DO only)
Default = 2000
X6^
= DTP remote power
0 = No remote power (default)
1 = DTP
2 = DTP2
X6&
= TP format
0 = DTP format (default)
1 = XTP format
2 = HDBaseT format
X7)
= Hot plug change or detection
1 = A new sink has been connection (assertion)
2 = HDBaseT format (available only on Output 1A of the
IN1804 DO and IN1804 DI/DO).
X7!
= Audio output mute
Local 5-pole captive screw analog output
is muted for all IN1804 models
1 = Local 5-pole captive screw analog audio output
connectors are muted for all IN1804 models.
Remote analog audio output connectors (DTP only)
are muted on IN1804 DO and IN1804 DI/DO only)
2 = Embedded TMDS audio output
X7@
= Key effect variable
0 = Transparency (available only when
X7$
= 1)
1 = Red of RGB key (available only when
X7$
= 2)
2 = Green of RGB key (available only when
X7$
= 2)
3 = Blue of RGB key (available only when
X7$
= 2)
4 = Level key (available only when
X7$
= 3)
X7#
= Key effect setting
0 through 255
X7$
=
Key effect
0 = Disabled
1 = Transparency
2 = RGB key
3 = Level key
4 = Alpha key
X7%
= Contact/Tally port number
1 through 7
X7^
= Contact/Tally port mode and
status
0 = Open
1 = Closed
X8)
= Audio playback file slot number
1 through 16
Highest priority for playback is slot 1, descending to
lowest priority slot 16.
