Input and Output Card Arrangements
The Quantum card frames are configured to order. Therefore, the combination and
position of cards varies depending on your specified configuration. At least one output
card and one input card are required. Other than that, any number or combination of input
and output cards can be used, depending on the number of input or output channels
required and the number of available slots.
NOTE: In a standard configuration, output cards are installed in the highest numbered
slots, in other words, slot 15 downwards on the Quantum Elite 615 or slot 8
downwards on the Quantum Elite 408. On the Quantum Connects, output cards are
installed in slot 8 (82 models) or 7 and 8 (84 models). Input cards are installed in the
remaining slots nearest the output cards.
Maximum number of inputs and outputs — Quantum Elite 615
Output
Cards
Output
Channels
Input
Cards
Video Input
channels
RGB, HD, DVI, and
SDI Input Channels
1 2 14 168 28
2 4 13 156 26
3 6 12 144 24
4 8 11 132 22
5 10 10 120 20
6 12 9 108 18
7 14 8 96 16
8 16 7 84 14
9 18 6 72 12
10 20 5 60 10
11 22 4 48 8
12 24 3 36 6
13 26 2 24 4
14 28 1 12 2
Maximum number of inputs and outputs — Quantum Elite 408 and
Quantum Connect
Output
Cards
Output
Channels
Input
Cards
Video Input
Channels
RGB, HDMI, DVI, and
SDI Input Channels
1 2 7 84 14
2 4 6 72 12
3 6 5 60 10
4 8 4 48 8
5 10 3 36 6
6 12 2 24 4
7 14 1 12 2
NOTES:
• A maximum of 128 sources can be viewed simultaneously with one output card.
• QGE 100 sources are transported over IP and require only a single video input
card to transfer QGE data to the RAPT bus.
