Room Scheduling System • Room Agent Installation and Configuration 36
4. Enter a name for the retrieved activity file (see figure 36,
1
).
1111111111
22
22222222
Figure 36. Panel Activity File
5. Click
Save (
2
). The Room Agent software saves the file. It reports that the Status is in
progress ( ) and then reports Activity retrieved. and All activities have been
retrieved successfully.
Retrieve a template
Templates allow you to create a number of customized panel appearances. Templates
are selectable using the Panel Design menu in the Panel Configuration window (see
figure 21,
7
on page 22 for an example). Templates can be created using a variety of tools
in the Panel Design window (see Panel Configuration Tab on page 21) and saved in the
template pane (see Templates pane on page 44).
You can retrieve the template assigned to a panel, for example to use as a starting point for
designing a new panel layout, as follows:
1. Right-click the panel in the Status column
1111111111
(see
see
1
, at right).
2. Click the pop-up Retrieve Template for
Design button (
2
). The Retrieve Template dialog box opens (see figure 37).
1111111111
Figure 37. Retrieve Template Dialog Box
3. Click
Retrieve (see figure 37,
1
). Room Agent software displays the
Retrieving Template ... activity indicator while it loads the template
and then automatically jumps to the Panel Design window (see Panel
Configuration Tab on page 21).
