Fargo DTC1250e - Page 19

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 19
.
Step
Procedure
10
Remove the 2 screws on the bottom right and left side to remove the inner back cover.
Right Side Left Side
12
Lift UP the bottom of this cover to release the upper tabs that hold the cover to the frame.
13
Reverse assembly instructions for replacing the covers.
