Complete Lamination Module Removal
1
If the Lamination Module needs to be removed from the printer completely then turn the printer over
and unscrew the 2 screws that attach the Lamination Module to the printer.
2
Remove the screw (F000178) from the Retainer Clip (D930077) that holds the Lamination Module to
the Printer.
Disconnect the Flipper Cable ( D930626)
