DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 31
.
Step
Procedure
3
Set the printer upright and move to the edge of the table. Unclip the tabs from below and move the
module outward. This will release the PCB connection within the door.
NOTE: When replacing the module carefully line up the PCB connection; push the module onto the
printer base to connect the PCB. Do not force or bend pins.
4
Procedure is complete. Reverse assembly to reinstall the Lamination Module.

Fargo DTC1250e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Print Resolution	300 dpi
Card Capacity	Input Hopper: 100 cards; Output Hopper: 30 cards
Card Sizes	CR-80, CR-79 Adhesive Back
Connectivity	USB 2.0
Memory	32 MB RAM
Card Thickness	9 mil to 40 mil
Operating System Support	Windows 7, 8, 10
