DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
.
Parts Replacement - Dual-Sided Printing Module
D930010-04 (Short Module) used for DTC1250e Flipper complete assembly
D930010-06 (Short Module) used for DTC4250e & 4500e Flipper complete assembly
MDP-00104 (Tall Module) used for DTC4500e Flipper complete assembly
IMPORTANT NOTE: The Flipper Table should be level when the Printer is powered up. If the Flipper Table is
at an angle, open the access door and manually level it. Then cycle the Printer Power to reset.
Remove all covers to access the Flipper Parts Replacements
