Fargo DTC1250e User Manual

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 4
.
Appendix C ............................................................................................................................................... 127
Lamination Module Mainboard connections ............................................................................................................... 127
Upper Sensing Cables ........................................................................................................................................... 127
Feed & Lower Sensing Cables .............................................................................................................................. 128
Upper Lam Head Cables ........................................................................................................................................ 129
Lower Lam Head Cables ........................................................................................................................................ 130
Lower Motor Cables ............................................................................................................................................... 131
Upper RFID and Ribbon Cable .............................................................................................................................. 132
Appendix D ............................................................................................................................................... 133
Engineering Drawings ............................................................................................................................................ 133

Fargo DTC1250e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Print Resolution	300 dpi
Card Capacity	Input Hopper: 100 cards; Output Hopper: 30 cards
Card Sizes	CR-80, CR-79 Adhesive Back
Connectivity	USB 2.0
Memory	32 MB RAM
Card Thickness	9 mil to 40 mil
Operating System Support	Windows 7, 8, 10
