DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 63
.
Step
Procedure
3
Remove the Damper Cap (F000487)
Use a thin flathead screwdriver to loosen one side.
The cap will pop off.
NOTE: Replace the Damper Cap by lining up the shaft first then snap the Damper Cap back on.
Verify the gray shaft is pushed up to hold the encoder wheel in place.

Fargo DTC1250e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Print Resolution	300 dpi
Card Capacity	Input Hopper: 100 cards; Output Hopper: 30 cards
Card Sizes	CR-80, CR-79 Adhesive Back
Connectivity	USB 2.0
Memory	32 MB RAM
Card Thickness	9 mil to 40 mil
Operating System Support	Windows 7, 8, 10
