DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 91
.
Step
Procedure
3
Remove the Retaining Ring (140048) and Platen Drive Gear ( 810265)
4
Remove the 3 screws (F000182) that hold the assembly to the frame.
Upper Module
Lower Module

Fargo DTC1250e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Print Resolution	300 dpi
Card Capacity	Input Hopper: 100 cards; Output Hopper: 30 cards
Card Sizes	CR-80, CR-79 Adhesive Back
Connectivity	USB 2.0
Memory	32 MB RAM
Card Thickness	9 mil to 40 mil
Operating System Support	Windows 7, 8, 10
