Fargo DTC4500 User Manual

© 2010 HID Global Corporation All rights reserved
DTC4500 Card Printer/Encoder User Guide L001444 Rev1.0
12
Technical Specifications
Term Function
Accepted Card
Types
PVC or polyester cards with polished PVC finish; monochrome
resin required for 100% polyester cards; optical memory cards
with PVC finish; rewrite
Input Hopper Card
Capacity
Dual-Input Card Hopper (200 cards)
Output Hopper Card
Capacity
100 cards (.030” / .762.mm)
Reject Hopper Card
Capacity
100 cards (.030” / .762.mm) – same-side Input/Output Card
Hopper or Lamination Module (required)
Card Cleaning Card cleaning roller integrated into the Ribbon Drawer.
Printer Memory 32MB RAM
Software Driver Windows® XP / Vista™ (32 bit & 64 bit) / Server 2003 & 2008 /
Windows® 7 / Linux®
Interface USB 2.0 and Ethernet with internal print server
Operating
Temperature
65 degrees to 80 degrees F / 18 degrees to 27 degrees C
Humidity 20-80% non-condensing
Dimensions
Single-Sided Printer: 9.8˝H x 18.1˝W x 9.2˝D / 249mmH x
460mmW x 234mmD
Dual-Sided Printer: 9.8˝H x 18.7˝W x 9.2˝D / 249mmH x
475mmW x 234mmD
Printer + Lam: 18.9˝H x 18.7˝W x 9.2˝D / 480mmH x 475mmW
x 234mmD

Fargo DTC4500 Specifications

General

Print Technology	Dye-sublimation / Resin thermal transfer
Resolution	300 dpi
Card Sizes	CR-80, CR-79 adhesive back
Memory	32 MB RAM
Power Requirements	100-240 VAC, 50-60 Hz
Card Capacity	200 cards input hopper, 100 cards output hopper
Connectivity	USB 2.0, Ethernet
Operating Systems	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	9.5 kg (20.9 lbs)
Dimensions	9.8" H x 9.2" D / 249 mm H x 234 mm D
Operating Temperature	15°C to 35°C (59°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Card Thickness	0.009" - 0.040" / 0.229 mm - 1.016 mm
