Selecting the Calibrate Laminator tab
The Calibrate Laminator tab is active when the Laminator is automatically detected or when the Laminator
is manually checked (as a Printer Feature on the Configuration tab). If the Laminator is not detected and
not manually checked, the tab is active; however, all functions are grayed out.
• Calibrate button: Sends calibrate Laminator command to Printer. Follow the instruction on the page
for setting up the Printer.
• Help button: Launches help specific to this tab.
Step Procedure
1 Select the Calibrate Laminator tab.
a. Ensure that the Cartridges are out of the Laminator.
b. Ensure the Laminator Cover is closed.
c. Click on the Calibrate button. (Note: The Printer’s LCD will display
CALIBRATE PASSED.
d. Click on the OK button on the LCD display to complete the procedure.
