Fargo DTC4500 User Manual

© 2010 HID Global Corporation All rights reserved
DTC4500 Card Printer/Encoder User Guide L001444 Rev1.0
5
Section 1: Specifications
The purpose of this section is to provide you with specific information on the Regulatory Compliances,
Agency Listings, Technical Specifications and Functional Specifications for the DTC4500 Card Printer
User Guide.
Regulatory Compliances
Term Description
CSA
(cUL)
The Printer manufacturer has been authorized by UL to
represent the Card Printer as CSA Certified under CSA
Standard C22.2 No. 60950-1-03.
File Number: E145118
FCC The Card Printer complies with the requirements in Part 15 of
the FCC rules for a Class A digital device.
EMC The Card Printer has been tested and complies with EN55022 /
CISPR 22 Class A: and EN55024 standards.
(Note: Based on the above testing, the Printer manufacturer
certifies that the Card Printer complies with current EMC
directive
2004/108/EC of the European Community and has
placed the CE mark on the Card Printer.)
License Number: J99032510
UL The Card Printer is listed under UL IEC 60950-1 (2001)
INFORMATION TECHNOLOGY EQUIPMENT
Note: This product is intended to be supplied by a Listed Power
Unit marked Class 2 and rated for 24 V dc, 3.7 to 5A
File Number: E145118
Environmental Power supply Efficiency level IV, RoHS, China RoHS

Fargo DTC4500 Specifications

General

Print Technology	Dye-sublimation / Resin thermal transfer
Resolution	300 dpi
Card Sizes	CR-80, CR-79 adhesive back
Memory	32 MB RAM
Power Requirements	100-240 VAC, 50-60 Hz
Card Capacity	200 cards input hopper, 100 cards output hopper
Connectivity	USB 2.0, Ethernet
Operating Systems	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	9.5 kg (20.9 lbs)
Dimensions	9.8" H x 9.2" D / 249 mm H x 234 mm D
Operating Temperature	15°C to 35°C (59°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Card Thickness	0.009" - 0.040" / 0.229 mm - 1.016 mm
