Fargo DTC4500 - Page 84

© 2010 HID Global Corporation All rights reserved
DTC4500 Card Printer/Encoder User Guide L001444 Rev1.0
84
Installing the Laminates
Step Procedure
3 Load lamination rolls into the cartridge until hearing a click.
4 Tighten the lamination roll.
5 Insert the overlaminate cartridge until hearing a click.
