FaroArm User Guide
January 2007
8
Chapter 1: Introduction to the FaroArm
For more information, see “Mounting Stiffness Test” on page 21.
Host Computer
The FaroArm output is accepted through any PC-compatible computer
USB port with a USB cable.
N
OTE: Complete all cable connections before applying power to
the computer and the FaroArm.
Numerical and Signal Processing
The FaroArm includes a complete electronics system located within the
body of the FaroArm. Signals from each joint are processed and
positional data is sent out to the computer.
Figure 1-5 FaroArm USB port
USB
PORT
On/Off
SWITCH
08M46E00_FaroArmUSB.book Page 8 Monday, January 15, 2007 1:12 PM
