Chapter 1: Introduction to the FaroArm
FaroArm Handle Buttons
The FRONT button is used to collect
data, and the BACK button to accept the
data.
• The FRONT button is green and
nearest the probe.
• The BACK button is red and is
nearest the handle.
The FaroArm has two sets of two buttons
and an LED, where the FRONT buttons
and BACK buttons are redundant and
wired together internally. When a button
is pressed, the LED light turns on (green
or red) and the Computer sounds. See
“Handle LED” on page 9.
LED
BACK BUTTON
FRONT BUTTON
BACK BUTTON
FRONT BUTTON
LED
