FaroArm User Guide
January 2007
38
Chapter 2: CAM2 Measure Devices Menu
WARNING: The probe must be well-seated in the hole when
digitizing all calibration points. Even one or two poorly digitized
points significantly affects the optimization process, which then has
an effect on the accuracy of the FaroArm.
The calibration points are then
calculated and the probe Calibration
Status is updated. If the probe passes,
then the current date and time is added
to the probe information.
You can view the details for all of the
calibrations of a probe by clicking the
View Log button. See “View Log” on
page 40.
• Digitize points in the hole and sweep to
position #2
• Digitize points in the hole and sweep to
position #3
Figure 2-4 Single Hole Method - Guidance
