Feig Electronic TST FUF2-C User Manual

TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 104 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
Pos: null /VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment + Klartext/Sicherheits- / Not-
Haltp-Kette @ 0\mod_1528356861031_6.docx @ 20098 @ @ 1
Pos: null /VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment + Klartext/Sicherheitsleiste
allgemein @ 0\mod_1528371175972_6.docx @ 20138 @ @ 4
Pos: null /VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment + Klartext/Funk-Steckmodul @
2\mod_1534858731413_6.docx @ 40583 @ @ 1
Pos: null /Steuermodule/------------ Seitenumbruch ------------ @ 0\mod_1452083281983_0.docx @ 742 @ @
1
Pos: null /VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment +
Klartext/Induktionsschleifendetektor @ 0\mod_1528357878597_6.docx @ 20114 @ @ 1
E.125
LCD-Display text of input +
Terminal No.
Input 25
E.126
LCD-Display text of input +
Terminal No.
Input 26
E.127
LCD-Display text of input +
Terminal No.
Input 27
E.128
LCD-Display text of input +
Terminal No.
Input 28
E.13A
LCD-Display text of input +
Terminal No.
Output 3A
E.13B
LCD-Display text of input +
Terminal No.
Input 3B
E.13C
LCD-Display text of input +
Terminal No.
Input 3C
E.13D
LCD-Text des Eingangs +Terminal
Nr.
Input 3D
E.13E
LCD-Display text of input +
Terminal No.
Input 3E
E.13F
LCD-Display text of input +
Terminal No.
Input 3F
Safety- / emergency stop chain
7-Segment display
Real text display
Description
E.201
Internal E-Stop
Internal emergency STOP
“mushroom buttom” triggered
E.211
External E-Stop 1
External emergency stop 1
triggered
E.212
External E-Stop 2
External emergency stop 2
triggered
Safety edge in general
7-Segment display
Real text display
Description
E.360
Safety edge tripped
Triggering of the first internal
safety edge
E.370
Safety edge tripped
Triggering of the first external
safety edge
E.380
Safety edge tripped
Triggering of the second internal
safety edge
E.3F0
Safety edge tripped
Triggering of the second external
safety edge
Wireless plug-in module
7-Segment display
Real text display
Description
E.401
Radio channel 1
Radio Channel 1
E.402
Radio channel 2
Radio Channel 2
Induction loop detector
7-Segment display
Real text display
Description
E.501
Loop 1
Detector channel 1
E.502
Loop 2
Detector channel 2
