4.2 Version in plastic housing (TST FUxF-xH)
The plastic version of the control consists of the mounting frame incl. printed circuit board, which is
inserted into the housing. The housing has the following dimensions:
179
415
89,5
430
210
Figure 4 Dimensions and drilling plan for FUxF-xH plastic housing
